2004-2010 Lotus Elise Factory Parts and Service Manual

$12.00

Covers: 2004 2005 2006 2007 2009 2010 Lotus Elise / Exige w/ Toyota 1ZZ/2ZZ engines and transmissions

Format: PDFs in zip file
Pages: 472 + supplements

Language: English

Category:

Product Description

Clear printable and searchable PDF. Instant download



The following is a list of topics contained in the Factory/OEM Lotus Workshop Manual (topics contain detailed sub-topics):

  • Technical Data
  • Chassis
  • Bodycare & Repair
  • Body Fittings
  • Front Suspension
  • Rear Suspension
  • Engine & Engine Management – Lotus supplement
    – Toyota 1ZZ/2ZZ engine repair manual see separate manual B120T0327J (not incl)
    – Toyota 2ZZ-GE engine supplement see separate manual C120T0327J (not incl)
  • Engine Management
  • Transmission – Lotus supplement
    – Toyota C64 transmission repair manual see separate manual D120T0327J (not incl)
    – Toyota C56 transmission repair manual see separate manual TBA (not incl)
  • Toyota 1ZZ/2ZZ-GE repair C60 (C64) C56 repair included (from 2000MY Celica)
  • Wheels & Tyres
  • Steering
  • Brakes
  • Engine Cooling
  • Fuel System
  • Electrics
  • Wiring Diagrams
  • Maintenance & Lubrication
  • Air Conditioning Heating & Ventilation
  • Clutch
  • Passive Restraint (North America)
  • Supplement – Exige Supercharged (S/C)
  • Supplement – 2-Eleven
  • Parts Manual

Additional Information

Model

Elise

Make

Lotus
